1 / 4

Turbine Design Operating Parameters:-  Steam Inlet Pressure (kg/cm2G) : 14  Steam Inlet Condition : >97% Dry Saturated  Steam Inlet Temperature (°C) : Saturated  Steam Exhaust Pressure (kg/cm2G) : 6.1  Steam Exhaust Condition : Saturated about 96% dry  Steam Exhaust Temperature (°C) : Saturated  Steam Flow Rate (kg/hr) : 14000 ( 9+5=14TPH)  Electrical Power (kW) :280 Kwh (5%Tolerance)  Generator Rating (kW) : 350 Kwh  Model : 550BG- Dual Valve
